Illumination & Stray Light !NEW!
Using the non-sequential mode of Zemax OpticStudio, you'll discover how to design illumination systems and run stray light analyses.
Illumination & Stray Light Learning Plan
This learning plan consists of 7 courses [+2 additional courses for the getting started course and the final exam], covering 4 days worth of material. The purchase of this learning plan gives you access to the online training platform for 30 calendar days.
It is the recommended training for non-sequential mode and assumes a background in optics but not necessarily with Zemax OpticStudio.
Training objectives:
- Model and analyze the performance of an illumination system in OpticStudio
- Build merit functions to optimize system performance and tolerance it
- Build a complex object
- Run a Stray Light Analysis
Courses included in this learning plan:
Getting started
This lesson gives you instructions for the course
$300
Introduction to Non-Sequential
This course is an introduction to non-sequential mode and ray-tracing in that mode. It will cover how sources and detectors are defined along with some radiometry reminders.
$310
Illumination Systems: Optimization and Tolerancing
This course will explain how to set-up, optimize and tolerance illumination systems.
$310
Complex Object Geometries
This course will explain how to create a complex object geometry when it doesn't exist as a built-in object.
$310
Polarization and Ray Splitting
This course will describe the tools for polarization and will then look at what happens when a ray splits.
$310
Non-Sequential Settings
This course will review the settings to terminate rays and common settings that can cause errors. It will also describe mixed-mode systems.
$310
Scattering and Photoluminescence
This course will review the different models for Surface Scattering as well as Bulk-Scattering and Photoluminescence Model.
$310
Stray Light
This course will study the Stray Light in a Maksutov telescope. It will demonstrate some useful tools like filter strings, ray files and path analysis.
$310
Illumination & Stray Light with Zemax OpticStudio, Exam
Earn your OpticStudio Certificate and share with your peers!
$310
